Product Details
- Size: 117
- Place of Origin: China
- Brand Name: HUACHI
- Model Number: LHT9406CLXY
- Weight: 12500.000 kg
| Vehicle Name | Dump trailer | Vehicle category | Trailer |
| Chinese brands | Tai Cheng cards | English brand | |
| Notice batch | 227 | Inspection | no |
| Engine brand | Fuel Type | (mm) | |
| Dimensions | 12500,13000×2500×3380,3580,3780,3980(mm) | Compartment Size | 12350,12850×2350×600(mm) |
| The total mass | 40000(Kg) | Carrying utilization factor | 0 |
| Curb weight | 6000(Kg) | Rated contained mass | 34000(Kg) |
| Quality Trailer | (kg) | Tractor saddle | 16000 |
| Cab | Front passenger | (People) | |
| Rated capacity | (People) | ABS | have |
| Approach / departure angle | -/14(°) | Front / rear overhang | -/2160,-/2280(mm) |
| Axle load | -/24000(And the loading axis) | Wheelbase | 6620+1310+1310,7000+1310+1310(mm) |
| Number of axes | 3 | The maximum speed | (km/h) |
| Fuel consumption | Number of spring | -/8/8/8,-/10/10/10 | |
| Number of tires | 12 | Tire Size | 11.00R20 12PR,12R22.5 12PR |
| Front track | Rear track | 1840/1840/1840 | |
| Brake ago | After braking | ||
| Operating system before | Post-production operation | ||
| Steering Type | Starting method | ||
| Chassis emission standards | |||
| Transmission Type | According to the standard | ||
| Release Date | 20131024 | Corporate identity | Anhui Long Road Traffic Technology Co., Ltd. |
| Vin Vehicle Identification Code | LS93CNS7×××LHC××× LS93CNS8×××LHC××× | ||
| Vehicle Notes | Compartment floor to the top of the fence height: 1800mm, 2000mm, 2200mm, 2400mm, optional vehicle shape structure; optional rear door style column cartridge compartment can be used in the form of interpolation or extrapolation, car plate optional flat structure, each optional side car plates 5 and 6, warehouse gate optional one, two, three, and the car cargo floor beams are made of high-quality high-strength lightweight steel ST700, so lighter curb weight. lateral protective materials are Q235 profiles, side protection for the bolted connection between the guard and the frame is connected to a fixed connection (welding), cross-sectional dimensions of the protection profiles: 160mm × 60mm, ground clearance: 550mm; ABS Model: VIE-III, production enterprises: Shanghai Wan Jie Vehicle Control system Co., Ltd. | ||
